HP StorageWorks

HPE XP7 Storage provides top performance, extreme availability, easy consolidation capability and unconditional HPE support and investment protection. Designed for applications requiring 100% data availability with no downtime, the XP7 combines a seven 9s platform of fully online scalable, fully redundant hardware, with ultra-high-performance, and advanced data replication, disaster recovery and online data migration capabilities.

HPE XP7 High Availability Software enables continuous access to XP7 data - even in the case of a complete data center disaster - by enabling an XP7 solution with fourteen 9s availability. The Flash Module Device compression engine delivers double the flash capacity along with world class performance and makes mission critical flash more affordable.

With 6.4 TB Flash Module Drive, XP7 has one of the most dense Flash drives in industry XP7 supports open systems, mainframe, and HPE NonStop all on a single XP7.


  • 6.8 PB Raw
  • 5.9 PB Useable
  • 247 PB External Storage
  • Maximum Supported Capacities
Drive description
  • (2304) SFF SAS or
  • (1152) LFF SAS or
  • (384) SFF SAS/SSD or
  • (576) Flash Module SAS
  • Maximum Supported Quantity of Media Form Factors
  • HPE XP7 supports combining multiple media formats in the same system.
Host interface
  • 16 Gb/8 Gb Fibre Channel (96) Ports or
  • 8 Gb Fibre Channel (192) Ports or
  • 8 Gb FICON (176) Ports or
  • 10 Gb FCoE (176) Ports
  • Supported
Availability features
  • All active components are redundant, and hot-swappable
  • 2 TB
  • Maximum Supported Capacity. Includes up to 80 GB of Shared Memory
Frames (range)
  • 1 – 6
Shared memory, maximum
  • 80 GB


Dimensions and weight


Dimensions (W x D x H)
24.1 x 43.8 x 79.0 in – per rack (61.0 x 111.2 x 200.6 cm – per rack)
1775 lbs – Based on a single DKC rack with 384 SFF HDDs (807 kg – Based on a single DKC rack with 384 SFF HDDs)


MICS Partner of ;

Buy / Sell

Check the correspondence between distributors


Remote maintenance Our exclusive remote maintenance solution performs real-time monitoring of your equipment and MICS alert when an incident occurs

Trained and certified technical staff MICS highly qualified and certified technical staff can provide support services for equipment maintenance and repair services for the Hitachi Universal Storage Platform USP V. Our contracts and maintenance services typically cost 50-70% less than what charge the original manufacturers.
